Single Pocket Door Kit
(0 Reviews)  Review this item

6 KITS TO CHOOSE FROM - TO SUIT 6 STANDARD DOOR SIZES...

Suitable for:

  • 35-44mm thick doors - up 60kgs in weight (door not included)
  • Fits 3"x2" stud (75mmx50mm) as well as other sizes - see below*
  • Double doors (just order two - joining brackets included in every single kit)

IN STOCK AND READY TO SHIP!

FREE! Shipping - UK Mainland Only - Order before 12PM for next working day delivery. (where possible)

NEED FURTHER HELP?? - INSTALLATION GUIDE - INSTALLATION VIDEO

Prefer to speak to someone? CONTACT OUR KNOWLEDGE TEAM 0113 245 8157 | info@spacesavingdoors.co.uk

OPTIONAL ACCESSORIES:



*Different size studwork can be used however the head timber above the track needs to always be 75mm, additional layers of plasterboard each side can then be used to make up the difference.  If you are still unsure please call out team on 0113 245 8157

PRODUCT CODE DOOR PANEL FRAME WIDTH OVERALL DIMS PRICE EX VAT QTY
DW (WIDTH) DH (HEIGHT) W (WIDTH) H (HEIGHT)
RP686 686 (27") 1981 (78") 75mm* 1390 2050 £139.95
RP762 762 (30") 1981 (78") 75mm* 1545 2050 £139.95
RP838 838 (33") 1981 (78") 75mm* 1695 2050 £144.95
RP726 726 2040 75mm* 1470 2110 £139.95
RP826 826 2040 75mm* 1670 2110 £139.95
RP926 926 2040 75mm* 1870 2110 £144.95
DescriptionSizeFormatGet File
Single Pocket Door Kit - Installation Guide2312287.pdfDOWNLOAD
Soft Close Unit413456.pdfDOWNLOAD
Jamb Installation Guides782622.pdfDOWNLOAD

*Different size studwork can be used however the head timber above the track needs to always be 75mm, additional layers of plasterboard each side can then be used to make up the difference.  If you are still unsure please call out team on 0113 245 8157



What's included in your order



  • All the galvanised steel uprights and horizontals required to build the pocket, plus the track.

  • The brackets to fit the frame to the stud work that double as plasterboard positioners and supports.

  • Adjustable pocket entrance guide which will enable you to assemble the kit for a 35mm or 44mm door.

  • Runners with carbon steel 'sealed for life' bearings that insert easily into the track.

  • A door brake.

  • Door brackets for the top of the door, rear door stop, door brake, and fixings. Adjustable bolt and nuts for
    runners plus spanner. Screws to assemble frame and screws to attach plasterboard to pocket.

  • A 12 year guarantee

  • Instruction booklet
